Features:

12.1' inch colored, high definition ( 800 x 600) TFT screen
Parameters: SPO2, ECG, NIBP, TEMP, RESP
Suitable for adult, pediatric and neonatal patients
72 hours graphic and tabular trends of all parameters
32 seconds full-disclosure waveform review
500 NIBP measurement data can be stored and recalled
Storage and recall of 500 SpO2 measurement data
Built-in rechargeable Lithium battery
Equiped with internal printer

Technical Specifications:

1. Parameters: SPO2, ECG, NIBP, TEMP, RESP, PR, RR. Optional Function: ETCO2 and internal printer.

2. Power supply
AC power adapter, AC 85~ 265V/ 50Hz/ 60Hz;
lithium battery.

3. SpO2
Range: 0% -100% .
Accuracy: ± 2% at 70-100% ; < 70% , undefined.

4. Pulse rate
Range: 30-250bpm.
Accuracy: ± 2bpm at 30-250bpm.

5. NIBP
Method: Oscillometry
Modes: Manual/ Auto/ Comtinuous
Auto measure time: Adjustable
Measurement range: 10-270mmHg

6. ECG
Lead mode: 3-lead or 5-lead
Lead selection: I; II; III, avR; avF; V
Heart rate range: Adult: 15-300bpm; Pediatric/ Neonatal: 15-300bpm
ECG waveform: 2 channals
Accuracy: ± 1 bpm or ± 1% , which is greater
S-T segment detection; measurement range: -2.0mv~ 2.0mv
Alarm: Yes, audible and visual alarm, alarm events review

7. Respiration
Method: RA-LL impedance
Range: Adult: 0-120rpm; pediatric/ neonatal: 0-150rpm
Apnca alarm: Yes

8. Temperature

Range: 0-500C
Accuracy: ± 0.10C
Channal: Dual-channel

Environment Specification:

Operating Temp.: 0 to 45° c
Storage Temp.: -20 to + 60° c
Relative Humidity: 30 to 95% ( Operating) , 10 to 95% ( Storage)

Standard Package:

PM5000 Main Uint
Adult SpO2 Probe
5-leads ECG Cable
Electrodes
NIBP Cuff for Adult
NIBP Extension Tube
Power cable
Battery
user manual
